Dot

Foster + Partners

Dot is a family of pendant lamps designed by Foster + Partners to make luminaires look like disks of light.

Their design neatly combines formal rigour and the most advanced lighting technology. Dot has two differently sized parallel disks connected through their centres by a thin metal tube. The bottom, smaller disk is turned aluminium and contains a LED ring optically engineered to cast a high quantity of light onto the top disk, the diffuser, made of lacquered aluminium.

The high-powered source generates an amount of heat that the bottom disk could not dissipate on its own. The problem was solved by placing a special heat sink (used in the aerospace industry) in the thin tube connecting the disks. Its function is to thermally connect the LED circuit to a heat dissipator housed in the top disk.
On being switched on, the Dot is a thin, lightweight disk, seemingly suspended in mid-air, that generates an enveloping flux of light without shadows.

Dot comes in three different diameters and power ratings: ø60cm (23W), ø80cm (41W), ø110cm (55W). There are two finishes: anodized black and anodized brass.

Gallery

Interactive model




LEGEND

Orbit mode

Move camera: 1 finger drag or Left Mouse Button
Pan: 2-finger drag or Right Mouse Button or SHIFT+ Left Mouse Button
Zoom on object: Double-tap or Double-click on object
Zoom out: Double-tap or Double-click on background
Zoom: Pinch in/out or Mousewheel or CTRL + Left Mouse Button

Lighting

Rotate all lighting: 3-finger drag (on mobile) or ALT + Left Mouse Button
Rotate environment only: ALT + SHIFT + Left Mouse Button
Rotate real-time lights only: ALT + CONTROL + Left Mouse Button

Real application

Tech Specs

Dot 1100

Model

Dot 1100

Code

132

Source

52W LED

High Color Rendering Index

Correlated Color Temperature 3000K or 2700K

Energy Class E

Dimmable

Dali system compatible

Insulation Class I

CE listed

ETL listed

UK CA listed

dot_1100

Dot 800

Model

Dot 800

Code

131

Source

39W LED

High Color Rendering Index

Correlated Color Temperature 3000K or 2700K

Energy Class E

Dimmable

Dali system compatible

Insulation Class I

CE listed

ETL listed

UK CA listed

dot_800

Dot 600

Model

Dot 600

Code

130

Source

21W LED

High Color Rendering Index

Correlated Color Temperature 3000K or 2700K

Energy Class E

Dimmable

Dali system compatible

Insulation Class I

CE listed

ETL listed

UK CA listed

dot_600
